MAPLE LEAF 45

Sailboat Specifications

both US imperial metric

Hull Type:

Fin with rudder on skeg

Rigging Type:

Masthead Sloop

LOA:

45.00 ft / 13.72 m

LWL:

37.75 ft / 11.51 m

Beam:

14.00 ft / 4.27 m

S.A. (reported):

862.00 ft² / 80.08 m²

Draft (max):

6.25 ft / 1.91 m

Displacement:

27,700 lb / 12,565 kg

Ballast:

9,200 lb / 4,173 kg

S.A./Disp.:

15.13

Bal./Disp.:

33.21

Disp./Len.:

229.87

Construction:

FG w/foam cored hull, balsa deck.

First Built:

1985

Builder:

Copper Enterprises (CAN)

Designer:

Stan Huntingford

Auxiliary Power/Tanks (orig. equip.)

Type:

Diesel

HP:

52

Fuel:

125 gals / 473 L

Sailboat Calculations

Definitions

S.A./Disp.:

15.13

Bal./Disp.:

33.21

Disp./Len.:

229.87

Comfort Ratio:

31.91

Capsize Screening Formula:

1.85

Accommodations

Water:

175 gals / 662 L

Sailboat Links

Designers:

Stan Huntingford

Builders:

Cooper Enterprises Inc. (CAN)

Download Boat Record:

PDF

Notes

Shoal Draft: 5'.
