Sailboat Specifications

Definitions
Hull Type: Dbrd. Dinghy
Rigging Type: Cat (unstayed)
LOA: 14.00 ft / 4.27 m
LWL: 14.00 ft / 4.27 m
S.A. (reported): 97.00 ft² / 9.01 m²
Beam: 5.20 ft / 1.58 m
Displacement: 120.00 lb / 54 kg
Construction: FG
First Built: 2016
Builder: Melges Boat Co.
Designer: Reichel/Pugh

KLSC Leaderboard

KLSC Leaderboard

Sailboat Calculations

Definitions
S.A. / Displ.: 63.82
Disp: / Len: 19.52
Comfort Ratio: 1.47
Capsize Screening Formula: 4.22
Hull Speed: 5.01 kn
Pounds/Inch Immersion: 260.12 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: Reichel/Pugh Yacht Design
Builders: Melges Performance Sailboats
Dealers: East Coast Sailboats
Download Boat Record:

Notes

SAILS for different weights and/or conditions:
Full-Range: 98 sq ft /9.1 m2
Mid-Range: 85 sq ft /7.8 m2
