MISIL II (HALLBERG-RASSY)

Sailboat Specifications

both US imperial metric

Hull Type:

Fin with rudder on skeg

Rigging Type:

Masthead Sloop

LOA:

24.11 ft / 7.35 m

LWL:

19.85 ft / 6.05 m

Beam:

7.55 ft / 2.30 m

S.A. (reported):

301.39 ft² / 28.00 m²

Draft (max):

3.94 ft / 1.20 m

Displacement:

4,079 lb / 1,850 kg

Ballast:

1,894 lb / 859 kg

S.A./Disp.:

18.94

Bal./Disp.:

46.43

Disp./Len.:

232.82

Construction:

FG

Ballast Type:

Incapsulated steel

First Built:

1972

Last Built:

1977

# Built:

596

Builder:

HALBERG-RASSY

Designer:

Olle Enderlein

Auxiliary Power/Tanks (orig. equip.)

Type:

Outboard

Sailboat Calculations

Definitions

S.A./Disp.:

18.94

Bal./Disp.:

46.43

Disp./Len.:

232.82

Comfort Ratio:

20.20

Capsize Screening Formula:

1.89

Rig and Sail Particulars

help

Mast Height from DWL:

32.32 ft / 9.85 m

Sailboat Links

Designers:

Olle Enderlein

Builders:

Hallberg-Rassy

Download Boat Record:

PDF

Notes

Early boats had lead keels. Weight: 740 kg/1,631 lbs.
Inboard motor optional.
