MORGAN 22

Sailboat Specifications

both US imperial metric

Hull Type:

Keel/Cbrd.

Rigging Type:

Masthead Sloop

LOA:

21.42 ft / 6.53 m

LWL:

20.33 ft / 6.20 m

Beam:

8.00 ft / 2.44 m

S.A. (reported):

238.00 ft² / 22.11 m²

Draft (max):

4.92 ft / 1.50 m

Draft (min):

1.80 ft / 0.55 m

Displacement:

2,700 lb / 1,225 kg

Ballast:

1,400 lb / 635 kg

S.A./Disp.:

19.69

Bal./Disp.:

51.85

Disp./Len.:

143.45

Construction:

FG

Ballast Type:

Lead

First Built:

1968

Last Built:

1971

Builder:

Morgan Yachts (USA)

Designer:

Charles Morgan

Sailboat Calculations

Definitions

S.A./Disp.:

19.69

Bal./Disp.:

51.85

Disp./Len.:

143.45

Comfort Ratio:

12.66

Capsize Screening Formula:

2.30

S#:

3.86

Rig and Sail Particulars

help

I:

27.00 ft / 8.23 m

J:

8.50 ft / 2.59 m

P:

23.50 ft / 7.16 m

E:

10.50 ft / 3.20 m

S.A. Fore:

114.75 ft² / 10.66 m²

S.A. Main:

123.38 ft² / 11.46 m²

S.A. Total (100% Fore + Main Triangles)

238.13 ft² / 22.12 m²

S.A./Disp. (calc.):

19.70

Est. Forestay Len.:

28.31 ft / 8.63 m
