MORGAN 31 (LAVRANOS)

Sailboat Specifications

both US imperial metric

Hull Type:

Long keel w/trans. hung rudder

Rigging Type:

Masthead Sloop

LOA:

30.52 ft / 9.30 m

LWL:

25.00 ft / 7.62 m

Beam:

10.33 ft / 3.15 m

S.A. (reported):

365.00 ft² / 33.91 m²

Draft (max):

4.76 ft / 1.45 m

Displacement:

11,984 lb / 5,436 kg

Ballast:

3,889 lb / 1,764 kg

S.A./Disp.:

11.19

Bal./Disp.:

32.45

Disp./Len.:

342.40

Construction:

FG

Ballast Type:

Lead

First Built:

1978

Builder:

Morgan Mosenthal Marine (SA)

Designer:

Angelo Lavranos

Auxiliary Power/Tanks (orig. equip.)

Type:

Diesel

Fuel:

48 gals / 182 L

Sailboat Calculations

Definitions

S.A./Disp.:

11.19

Bal./Disp.:

32.45

Disp./Len.:

342.40

Comfort Ratio:

30.98

Capsize Screening Formula:

1.81

S#:

1.32

Rig and Sail Particulars

help

I:

40.19 ft / 12.25 m

J:

13.32 ft / 4.06 m

P:

35.10 ft / 10.70 m

E:

12.53 ft / 3.82 m

S.A. Fore:

267.67 ft² / 24.87 m²

S.A. Main:

219.90 ft² / 20.43 m²

S.A. Total (100% Fore + Main Triangles)

487.57 ft² / 45.30 m²

S.A./Disp. (calc.):

14.95

Est. Forestay Len.:

42.34 ft / 12.91 m

Accommodations

Water:

178 gals / 674 L
