Sailboat Specifications

Definitions
Hull Type: Fin w/bulb & spade rudder
Rigging Type: Fractional Sloop
LOA: 35.76 ft / 10.90 m
LWL: 30.41 ft / 9.27 m
S.A. (reported): 683.00 ft² / 63.45 m²
Beam: 11.10 ft / 3.38 m
Displacement: 15,212.00 lb / 6,900 kg
Ballast: 5,512.00 lb / 2,500 kg
Max Draft: 6.23 ft / 1.90 m
Construction: FG
First Built: 2008
Builder: Najad Yachts (SWE)
Designer: Judel/Vrolijk

KLSC Leaderboard

KLSC Leaderboard

Auxiliary Power/Tanks (orig. equip.)

Make: Volvo Penta
Model: D1-30S
Type: Diesel
Fuel: 40 gals / 151 L

Accomodations

Water: 66 gals / 250 L

Sailboat Calculations

Definitions
S.A. / Displ.: 17.86
Bal. / Displ.: 36.23
Disp: / Len: 241.48
Comfort Ratio: 29.76
Capsize Screening Formula: 1.80
Hull Speed: 7.39 kn
Pounds/Inch Immersion: 1,206.11 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
Mast Height from DWL: 54.15 ft / 16.50 m

Sailboat Links

Designers: Judel/Vrolijk & Co.
Builders: Najad Yachts (SWE)
Download Boat Record:

Notes

Shallow draft: 1.70m/5.58'
