OCEANIS 473 (BENETEAU)

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/bulb & spade rudder

Rigging Type:

Masthead Sloop

LOA:

46.92 ft / 14.30 m

LWL:

43.83 ft / 13.36 m

Beam:

14.16 ft / 4.32 m

S.A. (reported):

898.00 ft² / 83.43 m²

Draft (max):

5.58 ft / 1.70 m

Displacement:

24,277 lb / 11,012 kg

Ballast:

8,157 lb / 3,700 kg

S.A./Disp.:

17.20

Bal./Disp.:

33.60

Disp./Len.:

128.72

Construction:

FG

Ballast Type:

Iron

First Built:

2000

Last Built:

2005

Builder:

Beneteau

Designer:

Groupe Finot

Auxiliary Power/Tanks (orig. equip.)

Type:

Diesel

Fuel:

57 gals / 216 L

Sailboat Calculations

Definitions

S.A./Disp.:

17.20

Bal./Disp.:

33.60

Disp./Len.:

128.72

Comfort Ratio:

24.58

Capsize Screening Formula:

1.96

S#:

3.73

Rig and Sail Particulars

help

I:

53.83 ft / 16.41 m

J:

18.25 ft / 5.56 m

P:

47.67 ft / 14.53 m

E:

17.08 ft / 5.21 m

S.A. Fore:

491.20 ft² / 45.63 m²

S.A. Main:

407.10 ft² / 37.82 m²

S.A. Total (100% Fore + Main Triangles)

898.30 ft² / 83.45 m²

S.A./Disp. (calc.):

17.21

Est. Forestay Len.:

56.84 ft / 17.32 m

Accommodations

Water:

222 gals / 840 L

Sailboat Links

Designers:

Jean Marie Finot (Groupe Finot)

Builders:

Beneteau

Related Sailboats:

BENETEAU 473

Download Boat Record:

PDF

Notes

Hull Length:46.42’
Draft(deep keel):6.92’
Ballast:(deep keel):7,275 lbs
Also called, or similar to, BENETEAU 473. See BENETEAU 473.
