O'DAY 240

Sailboat Specifications

both US imperial metric

Hull Type:

Wing Keel

Rigging Type:

Masthead Sloop

LOA:

24.58 ft / 7.49 m

LWL:

20.83 ft / 6.35 m

Beam:

8.25 ft / 2.51 m

S.A. (reported):

249.00 ft² / 23.13 m²

Draft (max):

2.67 ft / 0.81 m

Displacement:

3,600 lb / 1,633 kg

Ballast:

1,200 lb / 544 kg

S.A./Disp.:

17.01

Bal./Disp.:

33.33

Disp./Len.:

177.82

Construction:

FG

First Built:

1988

Last Built:

1989

Builder:

O'Day Corp. (USA)

Designer:

Hunt & Associates

Sailboat Calculations

Definitions

S.A./Disp.:

17.01

Bal./Disp.:

33.33

Disp./Len.:

177.82

Comfort Ratio:

15.24

Capsize Screening Formula:

2.16

S#:

2.98

Rig and Sail Particulars

help

I:

29.25 ft / 8.92 m

J:

9.00 ft / 2.74 m

P:

24.08 ft / 7.34 m

E:

9.75 ft / 2.97 m

S.A. Fore:

131.63 ft² / 12.23 m²

S.A. Main:

117.39 ft² / 10.91 m²

S.A. Total (100% Fore + Main Triangles)

249.02 ft² / 23.13 m²

S.A./Disp. (calc.):

17.01

Est. Forestay Len.:

30.60 ft / 9.33 m

Sailboat Links

Designers:

Raymond Hunt (C.R. Hunt & Assoc.)

Builders:

O'Day Corp.

Lear Siegler Inc.

Download Boat Record:

PDF

Notes

Reintroduced (or similar) as O'DAY 250 in 1996.
