PH 41

Sailboat Specifications

both US imperial metric

Hull Type:

Fin with rudder on skeg

Rigging Type:

Masthead Sloop

LOA:

41.00 ft / 12.50 m

LWL:

31.33 ft / 9.55 m

Beam:

12.00 ft / 3.66 m

S.A. (reported):

960.00 ft² / 89.19 m²

Draft (max):

6.50 ft / 1.98 m

Displacement:

16,500 lb / 7,484 kg

Ballast:

7,670 lb / 3,479 kg

S.A./Disp.:

23.79

Bal./Disp.:

46.48

Disp./Len.:

239.53

Construction:

FG

Ballast Type:

lead

First Built:

1975

Builder:

Philbrook's Shipyard (CAN)

Designer:

Perry/Huntingford

Auxiliary Power/Tanks (orig. equip.)

Type:

Diesel

HP:

42

Fuel:

45 gals / 170 L

Sailboat Calculations

Definitions

S.A./Disp.:

23.79

Bal./Disp.:

46.48

Disp./Len.:

239.53

Comfort Ratio:

27.22

Capsize Screening Formula:

1.89

Accommodations

Water:

100 gals / 379 L

Sailboat Links

Designers:

Robert Perry

Stan Huntingford

Builders:

Philbrook's Boatyard (CAN)

Download Boat Record:

PDF

Notes

IOR 2 ton.
