PRESTO 30

Sailboat Specifications

both US imperial metric

Hull Type:

Centerboard (Trunk)

Rigging Type:

Cat Ketch (unstayed)

LOA:

30.00 ft / 9.14 m

LWL:

28.75 ft / 8.76 m

Beam:

8.45 ft / 2.58 m

S.A. (reported):

400.00 ft² / 37.16 m²

Draft (max):

5.75 ft / 1.75 m

Draft (min):

1.12 ft / 0.34 m

Displacement:

3,950 lb / 1,792 kg

Ballast:

1,000 lb / 454 kg

S.A./Disp.:

25.68

Bal./Disp.:

25.32

Disp./Len.:

74.21

Construction:

FG

First Built:

2009

Builder:

Union River Boat Co. (USA)

Designer:

Rodger Martin

Sailboat Calculations

Definitions

S.A./Disp.:

25.68

Bal./Disp.:

25.32

Disp./Len.:

74.21

Comfort Ratio:

12.21

Capsize Screening Formula:

2.14

Sailboat Links

Designers:

Rodger Martin

Builders:

Union River Boat Co. (USA)

Download Boat Record:

PDF

Notes

Originally the HURRICAN ISLAND 30.
