Sailboat Specifications

Definitions
Hull Type: Fin w/spade rudder
Rigging Type: Masthead Sloop
LOA: 28.00 ft / 8.53 m
LWL: 24.00 ft / 7.32 m
S.A. (reported): 379.00 ft² / 35.21 m²
Beam: 9.67 ft / 2.95 m
Displacement: 6,700.00 lb / 3,039 kg
Ballast: 2,600.00 lb / 1,179 kg
Max Draft: 4.30 ft / 1.31 m
Construction: FG
First Built: 1982
Last Built: 1987
# Built: 120
Builder: Vandestadt and McGruer Ltd. (CAN)
Designer: Hubert Van de stadt

KLSC Leaderboard

KLSC Leaderboard

Auxiliary Power/Tanks (orig. equip.)

Make: Yanmar
Model: 1GM
Type: Diesel
HP: 7.5
Fuel: 19 gals / 72 L

Accomodations

Water: 24 gals / 91 L

Sailboat Calculations

Definitions
S.A. / Displ.: 17.12
Bal. / Displ.: 38.81
Disp: / Len: 216.37
Comfort Ratio: 20.01
Capsize Screening Formula: 2.05
S#: 2.53
Hull Speed: 6.56 kn
Pounds/Inch Immersion: 829.25 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 35.75 ft / 10.90 m
J: 11.16 ft / 3.40 m
P: 30.00 ft / 9.14 m
E: 12.00 ft / 3.66 m
S.A. Fore: 199.49 ft² / 18.53 m²
S.A. Main: 180.00 ft² / 16.72 m²
S.A. Total (100% Fore + Main Triangles): 379.49 ft² / 35.26 m²
S.A./Displ. (calc.): 17.14
Est. Forestay Length: 37.45 ft / 11.41 m

Sailboat Links

Designers: Hubert Vandestadt
Builders: Vandestadt and McGruer Ltd. (CAN)
