SNAPDRAGON 890

Sailboat Specifications

both US imperial metric

Hull Type:

Twin Keel

Rigging Type:

Masthead Sloop

LOA:

29.00 ft / 8.84 m

LWL:

24.00 ft / 7.32 m

Beam:

9.50 ft / 2.90 m

S.A. (reported):

376.00 ft² / 34.93 m²

Draft (max):

3.25 ft / 0.99 m

Displacement:

7,500 lb / 3,402 kg

Ballast:

3,000 lb / 1,361 kg

S.A./Disp.:

15.75

Bal./Disp.:

40.00

Disp./Len.:

242.20

Construction:

FG

First Built:

1971

Builder:

Thames Marine (UK)

Designer:

Thames Structural Plastics/Thames Marine

Auxiliary Power/Tanks (orig. equip.)

Make:

BMC

Type:

Diesel

HP:

32

Sailboat Calculations

Definitions

S.A./Disp.:

15.75

Bal./Disp.:

40.00

Disp./Len.:

242.20

Comfort Ratio:

22.66

Capsize Screening Formula:

1.94

Sailboat Links

Builders:

Thames Marine (UK)

Associations:

Snapdragon, Mirage and Invaders Association

Related Sailboats:

SNAPDRAGON 29

Download Boat Record:

PDF

Notes

Similar to SNAPDRAGON 29 but with a taller rig.
