SOMO 34

Sailboat Specifications

both US imperial metric

Hull Type:

Fin with rudder on skeg

Rigging Type:

Masthead Sloop

LOA:

33.14 ft / 10.10 m

LWL:

27.49 ft / 8.38 m

Beam:

10.50 ft / 3.20 m

S.A. (reported):

508.00 ft² / 47.19 m²

Draft (max):

5.84 ft / 1.78 m

Displacement:

9,480 lb / 4,300 kg

Ballast:

4,575 lb / 2,075 kg

S.A./Disp.:

18.21

Bal./Disp.:

48.26

Disp./Len.:

203.72

Construction:

FG

Ballast Type:

Iron

First Built:

1980

Builder:

Taylor (ESP)

Designer:

German Frers

Auxiliary Power/Tanks (orig. equip.)

Type:

Diesel

Sailboat Calculations

Definitions

S.A./Disp.:

18.21

Bal./Disp.:

48.26

Disp./Len.:

203.72

Comfort Ratio:

21.91

Capsize Screening Formula:

1.99

S#:

2.80

Rig and Sail Particulars

help

I:

43.14 ft / 13.15 m

J:

14.11 ft / 4.30 m

P:

39.37 ft / 12.00 m

E:

10.33 ft / 3.15 m

S.A. Fore:

304.35 ft² / 28.28 m²

S.A. Main:

203.35 ft² / 18.89 m²

S.A. Total (100% Fore + Main Triangles)

507.70 ft² / 47.17 m²

S.A./Disp. (calc.):

18.20

Est. Forestay Len.:

45.39 ft / 13.83 m

Sailboat Links

Designers:

German Frers

Related Sailboats:

CIRRUS 3/4 TON (FRERS)

Download Boat Record:

PDF
