SOVEREL 26 (1975)

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/spade rudder

Rigging Type:

Masthead Sloop

LOA:

26.20 ft / 7.99 m

LWL:

23.90 ft / 7.28 m

Beam:

10.10 ft / 3.08 m

S.A. (reported):

332.00 ft² / 30.84 m²

Draft (max):

4.60 ft / 1.40 m

Displacement:

4,750 lb / 2,155 kg

Ballast:

2,000 lb / 907 kg

S.A./Disp.:

18.85

Bal./Disp.:

42.11

Disp./Len.:

155.33

Construction:

FG

First Built:

1975

# Built:

25

Builder:

Soverel Marine (USA)

Designer:

Mark Soverel

Sailboat Calculations

Definitions

S.A./Disp.:

18.85

Bal./Disp.:

42.11

Disp./Len.:

155.33

Comfort Ratio:

13.72

Capsize Screening Formula:

2.41

S#:

3.55

Rig and Sail Particulars

help

I:

36.00 ft / 10.97 m

J:

10.80 ft / 3.29 m

P:

31.00 ft / 9.45 m

E:

8.90 ft / 2.71 m

S.A. Fore:

194.40 ft² / 18.06 m²

S.A. Main:

137.95 ft² / 12.82 m²

S.A. Total (100% Fore + Main Triangles)

332.35 ft² / 30.88 m²

S.A./Disp. (calc.):

18.87

Est. Forestay Len.:

37.59 ft / 11.46 m

Sailboat Links

Designers:

Mark Soverel

Builders:

Soverel Marine (USA)

Download Boat Record:

PDF

Notes

Designed specifically to the MORC handicap rule.
