Sailboat Specifications

Definitions
Hull Type: Fin w/spade rudder
Rigging Type: Fractional Sloop
LOA: 26.52 ft / 8.08 m
LWL: 21.92 ft / 6.68 m
S.A. (reported): 363.00 ft² / 33.72 m²
Beam: 8.75 ft / 2.67 m
Displacement: 3,900.00 lb / 1,769 kg
Ballast: 1,600.00 lb / 726 kg
Max Draft: 5.00 ft / 1.52 m
Construction: FG
Ballast Type: Lead
First Built: 1986
Last Built: 1987
# Built: 27
Builder: Tartan Marine (USA)
Designer: Mark Soverel

KLSC Leaderboard

KLSC Leaderboard

Auxiliary Power/Tanks (orig. equip.)

Make: Yanmar
Type: Diesel

Sailboat Calculations

Definitions
S.A. / Displ.: 23.51
Bal. / Displ.: 41.03
Disp: / Len: 165.31
Comfort Ratio: 14.39
Capsize Screening Formula: 2.23
S#: 3.96
Hull Speed: 6.27 kn
Pounds/Inch Immersion: 685.32 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 35.00 ft / 10.67 m
J: 10.00 ft / 3.05 m
P: 33.30 ft / 10.15 m
E: 11.28 ft / 3.44 m
S.A. Fore: 175.00 ft² / 16.26 m²
S.A. Main: 187.81 ft² / 17.45 m²
S.A. Total (100% Fore + Main Triangles): 362.81 ft² / 33.71 m²
S.A./Displ. (calc.): 23.49
Est. Forestay Length: 36.40 ft / 11.09 m

Sailboat Links

Designers: Mark Soverel
Builders: Soverel Marine (USA)
Tartan Marine
Download Boat Record:

Notes

Designed specifically for competition under the MORC(USA) rule.
