SOVEREL 39

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/spade rudder

Rigging Type:

Fractional Sloop

LOA:

38.42 ft / 11.71 m

LWL:

34.75 ft / 10.59 m

Beam:

12.50 ft / 3.81 m

S.A. (reported):

760.00 ft² / 70.61 m²

Draft (max):

7.67 ft / 2.34 m

Displacement:

11,783 lb / 5,345 kg

Ballast:

6,500 lb / 2,948 kg

S.A./Disp.:

23.57

Bal./Disp.:

55.16

Disp./Len.:

125.36

Construction:

FG w/balsa cored hull & deck

Ballast Type:

Lead

First Built:

1984

Last Built:

1988

Builder:

Soverel Marine (USA)

Designer:

Mark Soverel

Auxiliary Power/Tanks (orig. equip.)

Make:

Yanmar

Model:

3GMF

Type:

Diesel

HP:

Fuel:

15 gals / 57 L

Sailboat Calculations

Definitions

S.A./Disp.:

23.57

Bal./Disp.:

55.16

Disp./Len.:

125.36

Comfort Ratio:

17.58

Capsize Screening Formula:

2.20

S#:

4.65

Rig and Sail Particulars

help

51.00 ft / 15.54 m

14.75 ft / 4.50 m

49.00 ft / 14.94 m

15.00 ft / 4.57 m

S.A. Fore:

376.13 ft² / 34.94 m²

S.A. Main:

367.50 ft² / 34.14 m²

S.A. Total (100% Fore + Main Triangles)

743.63 ft² / 69.09 m²

S.A./Disp. (calc.):

23.06

Est. Forestay Len.:

53.09 ft / 16.18 m

Accommodations

Water:

25 gals / 95 L

Sailboat Links

Designers:

Mark Soverel

Builders:

Soverel Marine (USA)

Download Boat Record:

PDF

Notes

Wing keel version: 6.16'.
