SOVEREL 48

Sailboat Specifications

both US imperial metric

Hull Type:

Keel/Cbrd.

Rigging Type:

Staysail Ketch

LOA:

48.00 ft / 14.63 m

LWL:

40.00 ft / 12.19 m

Beam:

13.33 ft / 4.06 m

S.A. (reported):

900.00 ft² / 83.61 m²

Draft (max):

11.00 ft / 3.35 m

Draft (min):

5.43 ft / 1.66 m

Displacement:

27,762 lb / 12,593 kg

Ballast:

14,000 lb / 6,350 kg

S.A./Disp.:

15.77

Bal./Disp.:

50.43

Disp./Len.:

193.65

Construction:

FG

First Built:

1973

Last Built:

1987

# Built:

16

Builder:

Soverel Marine (USA)

Designer:

Bill Soverel

Website:

soverel48sailboat.webs.com

Auxiliary Power/Tanks (orig. equip.)

Make:

Lehman/Ford

Type:

Diesel

HP:

85

Fuel:

289 gals / 1,094 L

Sailboat Calculations

Definitions

S.A./Disp.:

15.77

Bal./Disp.:

50.43

Disp./Len.:

193.65

Comfort Ratio:

32.15

Capsize Screening Formula:

1.76

S#:

2.28

Rig and Sail Particulars

help

I:

50.00 ft / 15.24 m

J:

19.67 ft / 6.00 m

P:

43.50 ft / 13.26 m

E:

12.00 ft / 3.66 m

PY:

31.50 ft / 9.60 m

EY:

9.33 ft / 2.84 m

S.A. Fore:

491.75 ft² / 45.69 m²

S.A. Main:

261.00 ft² / 24.25 m²

S.A. Total (100% Fore + Main Triangles)

752.75 ft² / 69.93 m²

S.A./Disp. (calc.):

13.19

Est. Forestay Len.:

53.73 ft / 16.38 m

Accommodations

Water:

325 gals / 1,230 L
