Sailboat Specifications

Definitions
Hull Type: Long keel w/trans. hung rudder
Rigging Type: Masthead Sloop
LOA: 28.00 ft / 8.53 m
LWL: 22.00 ft / 6.71 m
Beam: 8.50 ft / 2.59 m
Displacement: 11,000.00 lb / 4,990 kg
Ballast: 4,000.00 lb / 1,814 kg
Max Draft: 4.75 ft / 1.45 m
Construction: Wood
Ballast Type: Iron
First Built: 1963
Last Built: 1965
# Built: 19
Builder: Uphams (UK)
Designer: Holman & Pye

KLSC Leaderboard

KLSC Leaderboard

Sailboat Calculations

Definitions
Bal. / Displ.: 36.36
Disp: / Len: 461.19
Comfort Ratio: 41.28
Capsize Screening Formula: 1.53
Hull Speed: 6.29 kn
Pounds/Inch Immersion: 668.17 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: Kim Holman
Builders: Upham (UK) (J. W. and A. Upham Ltd.)
Download Boat Record:
