SUPER SOVEREIGN

Sailboat Specifications

both US imperial metric

Hull Type:

Long Keel

Rigging Type:

Masthead Ketch

LOA:

35.00 ft / 10.67 m

LWL:

26.00 ft / 7.92 m

Beam:

10.00 ft / 3.05 m

S.A. (reported):

580.00 ft² / 53.88 m²

Draft (max):

4.99 ft / 1.52 m

Displacement:

16,350 lb / 7,416 kg

Ballast:

6,230 lb / 2,826 kg

S.A./Disp.:

14.46

Bal./Disp.:

38.10

Disp./Len.:

415.29

Construction:

FG

First Built:

1969

Last Built:

1975

# Built:

19

Builder:

J. W. and A. Upham Ltd. (UK)

Designer:

Holman and Pye

Auxiliary Power/Tanks (orig. equip.)

Make:

Thornycroft

Type:

Diesel

HP:

35

Fuel:

40 gals / 151 L

Sailboat Calculations

Definitions

S.A./Disp.:

14.46

Bal./Disp.:

38.10

Disp./Len.:

415.29

Comfort Ratio:

40.99

Capsize Screening Formula:

1.58

Accommodations

Water:

85 gals / 322 L

Sailboat Links

Designers:

Kim Holman

Builders:

Upham (UK) (J. W. and A. Upham Ltd.)

Associations:

Sovereign 35/Super Sovereign Owners

Download Boat Record:

PDF

Notes

A few of the early boats had a wood coachroof. A later version was called the BARBICAN 35.
