Sailboat Specifications

Definitions
Hull Type: Fin w/bulb & spade rudder
Rigging Type: Masthead Sloop
LOA: 82.28 ft / 25.08 m
LWL: 72.80 ft / 22.19 m
S.A. (reported): 3,314.00 ft² / 307.88 m²
Beam: 19.95 ft / 6.08 m
Displacement: 79,150.00 lb / 35,902 kg
Ballast: 39,683.00 lb / 18,000 kg
Max Draft: 13.12 ft / 4.00 m
Construction: FG
Ballast Type: Lead
First Built: 2010
Builder: Nautor (FIN)
Designer: German Frers

KLSC Leaderboard

KLSC Leaderboard

Auxiliary Power/Tanks (orig. equip.)

Make: Steyr
Model: MO196
Type: Diesel
HP: 190
Fuel: 396 gals / 1,499 L

Accomodations

Water: 340 gals / 1,287 L

Sailboat Calculations

Definitions
S.A. / Displ.: 28.90
Bal. / Displ.: 50.14
Disp: / Len: 91.58
Comfort Ratio: 30.05
Capsize Screening Formula: 1.86
S#: 6.26
Hull Speed: 11.43 kn
Pounds/Inch Immersion: 5,189.44 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 104.98 ft / 32.00 m
J: 30.84 ft / 9.40 m
P: 99.41 ft / 30.30 m
E: 34.10 ft / 10.39 m
ISP: 109.58 ft / 33.40 m
S.A. Fore: 1,618.79 ft² / 150.39 m²
S.A. Main: 1,694.94 ft² / 157.47 m²
S.A. Total (100% Fore + Main Triangles): 3,313.73 ft² / 307.86 m²
S.A./Displ. (calc.): 28.90
Est. Forestay Length: 109.42 ft / 33.35 m

Sailboat Links

Designers: German Frers
Builders: Nautor (Swan sailboats)
Download Boat Record:

Notes

Deck salon version of SWAN 80-2.
See SWAN 80-2 FD.
