Sailboat Specifications

Definitions
Hull Type: Centerboard Dinghy
Rigging Type: Fractional Sloop
LOA: 13.50 ft / 4.11 m
LWL: 12.42 ft / 3.79 m
S.A. (reported): 90.00 ft² / 8.36 m²
Beam: 5.50 ft / 1.68 m
Displacement: 315.00 lb / 143 kg
Max Draft: 2.75 ft / 0.84 m
Min Draft: 0.42 ft / 0.13 m
Construction: FG
First Built: 1970
Builder: Tanzer Industries Ltd. (CAN)
Designer: Johann Tanzer

KLSC Leaderboard

KLSC Leaderboard

Sailboat Calculations

Definitions
S.A. / Displ.: 31.14
Disp: / Len: 73.40
Comfort Ratio: 3.94
Capsize Screening Formula: 3.24
Hull Speed: 4.72 kn
Pounds/Inch Immersion: 244.08 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: Johann Tanzer
Builders: Tanzer Industries Ltd.
Download Boat Record:
