TEN-METER CLASS (1927)

Sailboat Specifications

both US imperial metric

Hull Type:

Fin Keel

Rigging Type:

Cutter

LOA:

58.70 ft / 17.89 m

LWL:

36.00 ft / 10.97 m

Beam:

10.50 ft / 3.20 m

S.A. (reported):

1,340.00 ft² / 124.49 m²

Draft (max):

7.50 ft / 2.29 m

Displacement:

28,000 lb / 12,701 kg

S.A./Disp.:

23.35

Disp./Len.:

267.92

Construction:

Wood with alternate steel frames

First Built:

1927

# Built:

14

Builder:

Abeking & Rasmussen

Designer:

Burgess, Rigg and Morgan

Sailboat Calculations

Definitions

S.A./Disp.:

23.35

Disp./Len.:

267.92

Comfort Ratio:

44.11

Capsize Screening Formula:

1.39

Sailboat Links

Designers:

W. Starling Burgess

Builders:

Abeking & Rasmussen

Associations:

Mystic Seaport Museum

Download Boat Record:

PDF

Notes

Commissioned by a group of New York yachtsmen in 1926. They raced as a one-design class on Long Island Sound in the late 1920's though they also rated 10 meters under the International rule.
