VARIANTA 44

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/bulb & spade rudder

Rigging Type:

Fractional Sloop

LOA:

43.73 ft / 13.33 m

LWL:

39.37 ft / 12.00 m

Beam:

13.65 ft / 4.16 m

S.A. (reported):

1,129.00 ft² / 104.89 m²

Draft (max):

7.32 ft / 2.23 m

Displacement:

21,605 lb / 9,800 kg

Ballast:

7,055 lb / 3,200 kg

S.A./Disp.:

23.38

Bal./Disp.:

32.65

Disp./Len.:

158.06

Construction:

FG

First Built:

2013

Builder:

Hanse Yachts

Designer:

Judel/Vrolijk

Auxiliary Power/Tanks (orig. equip.)

Make:

Volvo

Model:

D2-40

Type:

Diesel

HP:

40

Fuel:

32 gals / 121 L

Sailboat Calculations

Definitions

S.A./Disp.:

23.38

Bal./Disp.:

32.65

Disp./Len.:

158.06

Comfort Ratio:

25.27

Capsize Screening Formula:

1.96

S#:

3.78

Rig and Sail Particulars

help

I:

57.41 ft / 17.50 m

J:

17.06 ft / 5.20 m

P:

54.30 ft / 16.55 m

E:

19.36 ft / 5.90 m

S.A. Fore:

489.71 ft² / 45.50 m²

S.A. Main:

525.62 ft² / 48.83 m²

S.A. Total (100% Fore + Main Triangles)

1,015.33 ft² / 94.33 m²

S.A./Disp. (calc.):

21.02

Est. Forestay Len.:

59.89 ft / 18.25 m

Accommodations

Water:

74 gals / 280 L

Sailboat Links

Designers:

Judel/Vrolijk & Co.

Builders:

Hanse Yachts

Download Boat Record:

PDF

Notes

Shallow draft:
1.79m | 5.67´ (option)

CE Certificate: A (ocean)

Main sail: approx. 57.00 m²
Genoa 105%: approx. 48.00 m²

An intentionally no-frills build offered at a low cost.
In the tradition of the Dehler VARIANTA (1962).
