Sailboat Specifications

Definitions
Hull Type: Fin w/bulb and transom hung rudder
Rigging Type: Fractional Sloop
LOA: 26.25 ft / 8.00 m
LWL: 23.95 ft / 7.30 m
S.A. (reported): 430.56 ft² / 40.00 m²
Beam: 9.35 ft / 2.85 m
Displacement: 5,291.00 lb / 2,400 kg
Ballast: 2,205.00 lb / 1,000 kg
Max Draft: 3.28 ft / 1.00 m
Construction: FG
First Built: 2014
Builder: Winner Yachts (GER)
Designer: Cees van Tongeren/Van de Stadt Design

KLSC Leaderboard

KLSC Leaderboard

Auxiliary Power/Tanks (orig. equip.)

Make: Yanmar
Type: Diesel
HP: 9

Sailboat Calculations

Definitions
S.A. / Displ.: 22.75
Bal. / Displ.: 41.67
Disp: / Len: 171.94
Comfort Ratio: 16.90
Capsize Screening Formula: 2.15
Hull Speed: 6.56 kn
Pounds/Inch Immersion: 800.14 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: E. G. Van de Stadt
Builders: Winner Yachts
Download Boat Record:

Notes

Dual transom hung rudders.
Optional 14 hp Yanmar
Performance package:
- Draft 1.5m / 4.92ft
- Ballast 900 kg / 1,984 lbs
- Displacement 2,300 kg / 5,071 lbs
- SA 45 m² / 484 ft²
