YEOMAN JUNIOR

YEOMAN JUNIOR
YEOMAN JUNIOR

Beta Marine

Beta Marine

Sailboat Specifications

Definitions
Hull Type: Fin Keel
Rigging Type: Fractional Sloop
LOA: 33.08 ft / 10.08 m
LWL: 24.75 ft / 7.54 m
S.A. (reported): 469.00 ft² / 43.57 m²
Beam: 8.50 ft / 2.59 m
Displacement: 11,513.00 lb / 5,222 kg
Max Draft: 5.50 ft / 1.68 m
Construction: Wood
Ballast Type: Iron
First Built: 1954
Builder: R. J. Prior & Son Ltd. (UK)
Designer: Alan Buchanan

KLSC Leaderboard

KLSC Leaderboard

Auxiliary Power/Tanks (orig. equip.)

Make: Stuart Turner
Type: Gas
HP: 8

Sailboat Calculations

Definitions
S.A. / Displ.: 14.77
Disp: / Len: 339.01
Comfort Ratio: 37.74
Capsize Screening Formula: 1.51
Hull Speed: 6.67 kn
Pounds/Inch Immersion: 751.69 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: Alan Buchanan
Builders: Stebbings & Sons (UK)
Download Boat Record:

Notes

Called simply YEOMAN when first introduced.
