Sailboat Specifications

Definitions
Hull Type: Long Keel
Rigging Type: Masthead Sloop
LOA: 32.18 ft / 9.81 m
LWL: 28.94 ft / 8.82 m
S.A. (reported): 524.00 ft² / 48.68 m²
Beam: 10.93 ft / 3.33 m
Displacement: 12,345.00 lb / 5,600 kg
Ballast: 6,173.00 lb / 2,800 kg
Max Draft: 4.92 ft / 1.50 m
Construction: FG
Ballast Type: Iron
First Built: 1970
Last Built: 1985
# Built: 150
Builder: ACVA-Båt (SWE)
Designer: Lars Olof Norlin

Auxiliary Power/Tanks (orig. equip.)

Make: Volvo Penta
Model: MD11C
Type: Diesel

Sailboat Calculations

Definitions
S.A. / Displ.: 15.75
Bal. / Displ.: 50.00
Disp: / Len: 227.38
Comfort Ratio: 26.39
Capsize Screening Formula: 1.90
S#: 2.27
Hull Speed: 7.21 kn
Pounds/Inch Immersion: 1,130.23 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 44.49 ft / 13.56 m
J: 12.70 ft / 3.87 m
P: 37.73 ft / 11.50 m
E: 12.80 ft / 3.90 m
S.A. Fore: 282.51 ft² / 26.25 m²
S.A. Main: 241.47 ft² / 22.43 m²
S.A. Total (100% Fore + Main Triangles): 523.98 ft² / 48.68 m²
S.A./Displ. (calc.): 15.75
Est. Forestay Length: 46.27 ft / 14.10 m

Sailboat Links

Designers: Lars Olof Norlin
