Sailboat Specifications

Definitions
Hull Type: Centerboard (Trunk)
Rigging Type: Gaffhead Sloop
LOA: 21.33 ft / 6.50 m
LWL: 19.19 ft / 5.85 m
S.A. (reported): 213.00 ft² / 19.79 m²
Beam: 7.55 ft / 2.30 m
Displacement: 1,402.00 lb / 636 kg
Ballast: 123.00 lb / 56 kg
Max Draft: 3.74 ft / 1.14 m
Min Draft: 0.79 ft / 0.24 m
Construction: Plywood / FG
First Built: 1944
Last Built: 1974
# Built: 900
Builder: Madiana/Jouet
Designer: Eugène Cornu

Sailboat Calculations

Definitions
S.A. / Displ.: 27.26
Bal. / Displ.: 8.77
Disp: / Len: 88.57
Comfort Ratio: 7.39
Capsize Screening Formula: 2.70
Hull Speed: 5.87 kn
Pounds/Inch Immersion: 517.69 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: Eugène Cornu
Builders: Jouët (FRA)
Download Boat Record:

Notes

Built by professionals or amateurs (of wood from plans)and many still sailing in France.
More recent boats have been rigged as Bermudian/Marconi sloops (fractional).
