Sailboat Specifications

Definitions
Hull Type: Fin with rudder on skeg
Rigging Type: Cutter
LOA: 46.67 ft / 14.23 m
LWL: 36.25 ft / 11.05 m
S.A. (reported): 990.00 ft² / 91.97 m²
Beam: 13.67 ft / 4.17 m
Displacement: 33,000.00 lb / 14,969 kg
Ballast: 13,000.00 lb / 5,897 kg
Max Draft: 5.83 ft / 1.78 m
Construction: FG
First Built: 1990
Builder: Sherlock Marine Ltd. /Colvic Craft
Designer: Camper & Nicholson

Auxiliary Power/Tanks (orig. equip.)

Make: Perkins
Type: Diesel

Sailboat Calculations

Definitions
S.A. / Displ.: 15.46
Bal. / Displ.: 39.39
Disp: / Len: 309.27
Comfort Ratio: 39.79
Capsize Screening Formula: 1.71
Hull Speed: 8.07 kn
Pounds/Inch Immersion: 1,770.61 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: David Pedrick
Builders: Camper & Nicholsons
Colvic Craft
Download Boat Record:

Notes

This design was originally built by Camper & Nicholson (in-house design) and called the NICHOLSON 476. The molds were then sold to Colvic Craft where it was built as the BLUEWATER 476. (photo here is actually of the last NICHOLSON 476. )
(Thanks to Jeremy McGeary, former C&N employee, for supplying corrected information.)
