Sailboat Specifications
Hull Type:
Long Keel
Rigging Type:
Masthead Sloop
LOA:
35.18 ft / 10.72 m
LWL:
26.50 ft / 8.08 m
Beam:
11.00 ft / 3.35 m
S.A. (reported):
577.00 ft2 / 53.61 m2
Draft (max):
4.70 ft / 1.43 m
Displacement:
18,000 lb / 8,165 kg
Ballast:
5,000 lb / 2,268 kg
S.A./Disp.:
13.49
Bal./Disp.:
27.78
Disp./Len.:
431.80
Construction:
FG
Ballast Type:
Lead
First Built:
1965
Last Built:
1976
# Built:
100
Builder:
Chris-Craft (USA)
Designer:
Sparkman & Stephens
Auxiliary Power/Tanks (orig. equip.)
Make:
Perkins
Model:
4-107
Type:
Diesel
Fuel:
80 gals / 303 L
Sailboat Calculations
S.A./Disp.:
13.49
Bal./Disp.:
27.78
Disp./Len.:
431.80
Comfort Ratio:
39.21
Capsize Screening Formula:
1.68
S#:
0.82
Rig and Sail Particulars
I:
43.00 ft / 13.11 m
J:
12.87 ft / 3.92 m
P:
37.00 ft / 11.28 m
E:
16.25 ft / 4.95 m
S.A. Fore:
276.71 ft2 / 25.71 m2
S.A. Main:
300.63 ft2 / 27.93 m2
S.A. Total (100% Fore + Main Triangles)
577.33 ft2 / 53.64 m2
S.A./Disp. (calc.):
13.50
Est. Forestay Len.:
44.88 ft / 13.68 m
Accommodations
Water:
100 gals / 379 L
Sailboat Links
Designers:
Builders:
Related Sailboats:
Download Boat Record:
Notes
S&S design #1657.X.(this design was modified a number of times). Available as a sloop or ketch.Dimensions for ketch rig:I: 40.0'J: 12.87'P: 34.0'E: 14.0'PY: 20.0 EY: 8.0' Same hull as SAIL YACHT 35 (CHRIS-CRAFT).Information from original builders brochure.
