Sailboat Specifications

Definitions
Hull Type: Catamaran Twin Cbrd.
Rigging Type: Fractional Sloop
LOA: 39.00 ft / 11.89 m
LWL: 38.00 ft / 11.58 m
S.A. (reported): 870.00 ft² / 80.83 m²
Beam: 23.33 ft / 7.11 m
Displacement: 11,500.00 lb / 5,216 kg
Max Draft: 3.50 ft / 1.07 m
Construction: FG
First Built: 1989
Builder: Fountaine-Pajot (FRA)
Designer: Joubert-Nivelt/Olivier Flahault

Auxiliary Power/Tanks (orig. equip.)

Make: Volvo
Model: 2002
Type: Diesel X 2
HP: 36
Fuel: 66 gals / 250 L

Accomodations

Water: 210 gals / 795 L

Sailboat Calculations

Definitions
S.A. / Displ.: 27.42
Disp: / Len: 93.56
KSP: 0.85

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
Mast Height from DWL: 55.00 ft / 16.76 m

Sailboat Links

Designers: Flahault Design & Associates
Joubert-Nivelt
Builders: Fountaine Pajot
Download Boat Record:
