FIRST 33.7 (BENETEAU)

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/bulb & spade rudder

Rigging Type:

Fractional Sloop

LOA:

32.74 ft / 9.98 m

LWL:

28.81 ft / 8.78 m

Beam:

11.15 ft / 3.40 m

S.A. (reported):

523.00 ft² / 48.59 m²

Draft (max):

5.25 ft / 1.60 m

Displacement:

10,582 lb / 4,800 kg

S.A./Disp.:

17.42

Disp./Len.:

197.56

Construction:

FG

First Built:

2000

Builder:

Beneteau

Designer:

Berret-Racoupeau

Auxiliary Power/Tanks (orig. equip.)

Type:

Diesel

HP:

27

Fuel:

12 gals / 45 L

Sailboat Calculations

Definitions

S.A./Disp.:

17.42

Disp./Len.:

197.56

Comfort Ratio:

21.97

Capsize Screening Formula:

2.03

S#:

2.78

Rig and Sail Particulars

help

I:

41.67 ft / 12.70 m

J:

11.65 ft / 3.55 m

P:

38.39 ft / 11.70 m

E:

14.60 ft / 4.45 m

S.A. Fore:

242.73 ft² / 22.55 m²

S.A. Main:

280.25 ft² / 26.04 m²

S.A. Total (100% Fore + Main Triangles)

522.97 ft² / 48.59 m²

S.A./Disp. (calc.):

17.42

Est. Forestay Len.:

43.27 ft / 13.19 m

Accommodations

Water:

40 gals / 151 L

Sailboat Links

Designers:

Berret-Racoupeau

Builders:

Beneteau

Download Boat Record:

PDF
