FIRST 33.7 (BENETEAU)

FIRST 33.7 (BENETEAU)
FIRST 33.7 (BENETEAU)

Beta Marine

Beta Marine

Sailboat Specifications

Definitions
Hull Type: Fin w/bulb & spade rudder
Rigging Type: Fractional Sloop
LOA: 32.74 ft / 9.98 m
LWL: 28.81 ft / 8.78 m
S.A. (reported): 523.00 ft² / 48.59 m²
Beam: 11.15 ft / 3.40 m
Displacement: 10,582.00 lb / 4,800 kg
Max Draft: 5.25 ft / 1.60 m
Construction: FG
First Built: 2000
Builder: Beneteau
Designer: Berret-Racoupeau

Auxiliary Power/Tanks (orig. equip.)

Type: Diesel
HP: 27
Fuel: 12 gals / 45 L

Accomodations

Water: 40 gals / 151 L

Sailboat Calculations

Definitions
S.A. / Displ.: 17.42
Disp: / Len: 197.56
Comfort Ratio: 21.97
Capsize Screening Formula: 2.03
S#: 2.78
Hull Speed: 7.19 kn
Pounds/Inch Immersion: 1,147.80 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 41.67 ft / 12.70 m
J: 11.65 ft / 3.55 m
P: 38.39 ft / 11.70 m
E: 14.60 ft / 4.45 m
S.A. Fore: 242.73 ft² / 22.55 m²
S.A. Main: 280.25 ft² / 26.04 m²
S.A. Total (100% Fore + Main Triangles): 522.98 ft² / 48.59 m²
S.A./Displ. (calc.): 17.42
Est. Forestay Length: 43.27 ft / 13.19 m
