FIRST 35S7 (BENETEAU)

FIRST 35S7 (BENETEAU)
FIRST 35S7 (BENETEAU)

Beta Marine

Beta Marine

Sailboat Specifications

Definitions
Hull Type: Fin w/bulb & spade rudder
Rigging Type: Fractional Sloop
LOA: 34.58 ft / 10.54 m
LWL: 31.08 ft / 9.47 m
S.A. (reported): 591.00 ft² / 54.91 m²
Beam: 12.50 ft / 3.81 m
Displacement: 11,685.00 lb / 5,300 kg
Ballast: 3,748.00 lb / 1,700 kg
Max Draft: 6.06 ft / 1.85 m
Construction: FG
First Built: 1993
Last Built: 1995
Builder: Beneteau
Designer: Berret

Auxiliary Power/Tanks (orig. equip.)

Type: Diesel
Fuel: 24 gals / 91 L

Accomodations

Water: 85 gals / 322 L

Sailboat Calculations

Definitions
S.A. / Displ.: 18.43
Bal. / Displ.: 32.08
Disp: / Len: 173.76
Comfort Ratio: 19.45
Capsize Screening Formula: 2.21
S#: 3.22
Hull Speed: 7.47 kn
Pounds/Inch Immersion: 1,388.15 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 43.67 ft / 13.31 m
J: 12.08 ft / 3.68 m
P: 44.60 ft / 13.59 m
E: 14.67 ft / 4.47 m
S.A. Fore: 263.77 ft² / 24.51 m²
S.A. Main: 327.14 ft² / 30.39 m²
S.A. Total (100% Fore + Main Triangles): 590.91 ft² / 54.90 m²
S.A./Displ. (calc.): 18.42
Est. Forestay Length: 45.31 ft / 13.81 m
Mast Height from DWL: 54.81 ft / 16.71 m

Sailboat Links

Designers: Berret-Racoupeau
Philippe Stark
Builders: Beneteau
Download Boat Record:

Notes

Also sold as FIRST 35.7.
Shallow draft wing keel: 5.0'/1.52m.
Std. iron torpedo: 6.06'/1.85m
Deep keel (lead): 9.40'/1.95m
Relatively rare model.
With a different deck it became the FIRST 36S7 (BENETEAU).
