FIRST 36S7 (BENETEAU)

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/bulb & spade rudder

Rigging Type:

Fractional Sloop

LOA:

35.75 ft / 10.90 m

LWL:

31.08 ft / 9.47 m

Beam:

12.42 ft / 3.79 m

S.A. (reported):

660.00 ft² / 61.32 m²

Draft (max):

6.08 ft / 1.85 m

Displacement:

11,684 lb / 5,300 kg

Ballast:

3,650 lb / 1,656 kg

S.A./Disp.:

20.58

Bal./Disp.:

31.24

Disp./Len.:

173.74

Construction:

FG

First Built:

1996

Builder:

Beneteau

Designer:

Jean Berret

Auxiliary Power/Tanks (orig. equip.)

Type:

Diesel

HP:

27

Fuel:

24 gals / 91 L

Sailboat Calculations

Definitions

S.A./Disp.:

20.58

Bal./Disp.:

31.24

Disp./Len.:

173.74

Comfort Ratio:

19.40

Capsize Screening Formula:

2.19

S#:

3.27

Rig and Sail Particulars

help

I:

44.62 ft / 13.60 m

J:

12.96 ft / 3.95 m

P:

41.67 ft / 12.70 m

E:

15.09 ft / 4.60 m

S.A. Fore:

289.14 ft² / 26.86 m²

S.A. Main:

314.40 ft² / 29.21 m²

S.A. Total (100% Fore + Main Triangles)

603.54 ft² / 56.07 m²

S.A./Disp. (calc.):

18.82

Est. Forestay Len.:

46.46 ft / 14.16 m

Accommodations

Water:

80 gals / 303 L

Sailboat Links

Designers:

Philippe Stark

Berret-Racoupeau

Builders:

Beneteau

Download Boat Record:

PDF

Notes

Derived from the FIRST 35S7.
Deep keel: 6.92'
Wing keel: 4.83'.
Taller rig (IMS) also available. (P = 14.3m/46.92'.) Reported S.A. = 705 sqft
Not to be confused with the BENETEAU 36.7(FARR).
