Sailboat Specifications

Definitions
Hull Type: Centerboard Dinghy
Rigging Type: Fractional Sloop
LOA: 15.81 ft / 4.82 m
LWL: 14.17 ft / 4.32 m
S.A. (reported): 129.00 ft² / 11.98 m²
Beam: 5.84 ft / 1.78 m
Displacement: 287.00 lb / 130 kg
Max Draft: 3.94 ft / 1.20 m
Min Draft: 0.66 ft / 0.20 m
Construction: FG
First Built: 1957
Builder: La Prairie (FRA)
Designer: Jean-Jacques Herbulot

Sailboat Calculations

Definitions
S.A. / Displ.: 47.48
Disp: / Len: 45.03
Comfort Ratio: 2.88
Capsize Screening Formula: 3.54
Hull Speed: 5.04 kn
Pounds/Inch Immersion: 295.68 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: Jean-Jacques Herbulot
Builders: La Prairie (FRANCE)
Download Boat Record:

Notes

1 trapeze permitted.
