GRAVES 37

Sailboat Specifications

both US imperial metric

Hull Type:

Fin with rudder on skeg

Rigging Type:

Masthead Sloop

LOA:

37.17 ft / 11.33 m

LWL:

30.67 ft / 9.35 m

Beam:

12.17 ft / 3.71 m

S.A. (reported):

698.00 ft² / 64.85 m²

Draft (max):

5.75 ft / 1.75 m

Displacement:

16,220 lb / 7,357 kg

Ballast:

6,675 lb / 3,028 kg

S.A./Disp.:

17.49

Bal./Disp.:

41.15

Disp./Len.:

250.99

Construction:

FG

Ballast Type:

Lead

First Built:

1980

Builder:

Graves Yacht Yard (USA)

Designer:

J. Taylor

Auxiliary Power/Tanks (orig. equip.)

Fuel:

50 gals / 189 L

Sailboat Calculations

Definitions

S.A./Disp.:

17.49

Bal./Disp.:

41.15

Disp./Len.:

250.99

Comfort Ratio:

27.56

Capsize Screening Formula:

1.93

S#:

2.21

Rig and Sail Particulars

help

I:

49.90 ft / 15.21 m

J:

15.60 ft / 4.75 m

P:

44.50 ft / 13.56 m

E:

13.90 ft / 4.24 m

S.A. Fore:

389.22 ft² / 36.16 m²

S.A. Main:

309.28 ft² / 28.73 m²

S.A. Total (100% Fore + Main Triangles)

698.50 ft² / 64.89 m²

S.A./Disp. (calc.):

17.51

Est. Forestay Len.:

52.28 ft / 15.94 m

Mast Height from DWL:

54.60 ft / 16.64 m

Accommodations

Water:

100 gals / 379 L

Sailboat Links

Designers:

Jim Taylor

Builders:

Graves Yacht Yard (USA)

Download Boat Record:

PDF

Notes

The STARFLIGHT 38 was built to this same design by Starflight Yachts of Waterloo Ontario, CAN.
The numbers built for either one is unknown.
