HALLBERG-RASSY 26

HALLBERG-RASSY 26
HALLBERG-RASSY 26

Beta Marine

Beta Marine

Sailboat Specifications

Definitions
Hull Type: Fin w/transom hung rudder
Rigging Type: Fractional Sloop
LOA: 26.08 ft / 7.95 m
LWL: 20.67 ft / 6.30 m
S.A. (reported): 350.00 ft² / 32.52 m²
Beam: 8.79 ft / 2.68 m
Displacement: 5,511.00 lb / 2,500 kg
Ballast: 2,425.00 lb / 1,100 kg
Max Draft: 4.58 ft / 1.40 m
Construction: FG
Ballast Type: Cast iron
First Built: 1978
Last Built: 1985
# Built: 469
Builder: Hallberg-Rassy (SWE)
Designer: Olle Enderlein

Auxiliary Power/Tanks (orig. equip.)

Make: Volvo Penta
Model: MD 5A
Type: Diesel; Saildrive
HP: 7.5
Fuel: 11 gals / 42 L

Accomodations

Water: 17 gals / 64 L
Headroom: 5.25 ft / 1.60 m

Sailboat Calculations

Definitions
S.A. / Displ.: 18.00
Bal. / Displ.: 44.00
Disp: / Len: 278.59
Comfort Ratio: 21.12
Capsize Screening Formula: 1.99
Hull Speed: 6.09 kn
Pounds/Inch Immersion: 649.20 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
Mast Height from DWL: 39.37 ft / 12.00 m

Sailboat Links

Designers: Olle Enderlein
Builders: Hallberg-Rassy
Download Boat Record:

Notes

Specs are from a builder's brochure. A Hallberg-Rassy fleet brochure from 1981 lists the LWL as 6.7 m / 21.98 ft
