HALLBERG-RASSY 42 (ENDERLEIN)

HALLBERG-RASSY 42 (ENDERLEIN)
HALLBERG-RASSY 42 (ENDERLEIN)

Beta Marine

Beta Marine

Sailboat Specifications

Definitions
Hull Type: Fin with rudder on skeg
Rigging Type: Masthead Ketch
LOA: 42.42 ft / 12.93 m
LWL: 34.45 ft / 10.50 m
S.A. (reported): 850.35 ft² / 79.00 m²
Beam: 12.40 ft / 3.78 m
Displacement: 25,353.00 lb / 11,500 kg
Ballast: 9,920.00 lb / 4,500 kg
Max Draft: 6.73 ft / 2.05 m
Construction: GRP
Ballast Type: Steel
First Built: 1980
Last Built: 1991
# Built: 252
Builder: Hallberg-Rassy
Designer: Christoph Rassy / Olle Enderlein

Auxiliary Power/Tanks (orig. equip.)

Make: Volvo Penta
Model: MD 31A
Type: Diesel
HP: 62
Fuel: 104 gals / 395 L

Accomodations

Water: 192 gals / 725 L
Headroom: 6.07 ft / 1.85 m

Sailboat Calculations

Definitions
S.A. / Displ.: 15.83
Bal. / Displ.: 39.13
Disp: / Len: 276.83
Comfort Ratio: 37.20
Capsize Screening Formula: 1.69
S#: 1.57
Hull Speed: 7.87 kn
Pounds/Inch Immersion: 1,526.36 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 47.40 ft / 14.45 m
J: 16.40 ft / 5.00 m
P: 42.90 ft / 13.08 m
E: 14.66 ft / 4.47 m
PY: 24.60 ft / 7.50 m
EY: 8.20 ft / 2.50 m
S.A. Fore: 388.68 ft² / 36.11 m²
S.A. Main: 314.46 ft² / 29.21 m²
S.A. Total (100% Fore + Main Triangles): 703.14 ft² / 65.32 m²
S.A./Displ. (calc.): 13.09
Est. Forestay Length: 50.16 ft / 15.29 m
Mast Height from DWL: 53.38 ft / 16.27 m

Sailboat Links

Designers: Olle Enderlein
Builders: Hallberg-Rassy
Download Boat Record:

Notes

Also available with sloop rig.
Sloop mast above DWL: 17.74m / 58.2ft
Total SA:
101.5 m² (genoa, ketch)
95 m² (genoa, sloop).
79 m² (jib, ketch)
75.5 m² (jib, sloop).
