Sailboat Specifications

Definitions
Hull Type: Fin w/bulb & spade rudder
Rigging Type: Fractional Sloop
LOA: 31.59 ft / 9.63 m
LWL: 28.61 ft / 8.72 m
S.A. (reported): 518.00 ft² / 48.12 m²
Beam: 10.83 ft / 3.30 m
Displacement: 11,464.00 lb / 5,200 kg
Ballast: 3,263.00 lb / 1,480 kg
Max Draft: 6.04 ft / 1.84 m
Construction: FG
First Built: 2009
Builder: Hanse Yachts (GER)
Designer: Judel/Vrolijk

Auxiliary Power/Tanks (orig. equip.)

Type: Diesel
HP: 18
Fuel: 24 gals / 91 L

Accomodations

Water: 63 gals / 238 L

Sailboat Calculations

Definitions
S.A. / Displ.: 16.36
Bal. / Displ.: 28.46
Disp: / Len: 218.54
Comfort Ratio: 25.15
Capsize Screening Formula: 1.92
S#: 2.42
Hull Speed: 7.17 kn
Pounds/Inch Immersion: 1,107.11 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 40.85 ft / 12.45 m
J: 12.70 ft / 3.87 m
P: 38.39 ft / 11.70 m
E: 13.45 ft / 4.10 m
S.A. Fore: 259.40 ft² / 24.10 m²
S.A. Main: 258.17 ft² / 23.98 m²
S.A. Total (100% Fore + Main Triangles): 517.57 ft² / 48.08 m²
S.A./Displ. (calc.): 16.34
Est. Forestay Length: 42.78 ft / 13.04 m
Mast Height from DWL: 48.50 ft / 14.78 m

Sailboat Links

Designers: Judel/Vrolijk & Co.
Builders: Hanse Yachts
Download Boat Record:

Notes

Shallow Draft: 1.53m/5´ Updated version of HANSE 320.
