Sailboat Specifications

Definitions
Hull Type: Fin w/bulb & spade rudder
Rigging Type: Fractional Sloop
LOA: 34.74 ft / 10.59 m
LWL: 31.50 ft / 9.60 m
S.A. (reported): 697.00 ft² / 64.75 m²
Beam: 11.65 ft / 3.55 m
Displacement: 14,021.00 lb / 6,360 kg
Ballast: 4,067.00 lb / 1,845 kg
Max Draft: 6.30 ft / 1.92 m
Construction: FG
First Built: 2007
Builder: Hanse Yachts
Designer: Judel/Vrolijk

Auxiliary Power/Tanks (orig. equip.)

Make: Yanmar
Type: Diesel
HP: 22
Fuel: 32 gals / 121 L

Accomodations

Water: 63 gals / 238 L

Sailboat Calculations

Definitions
S.A. / Displ.: 19.25
Bal. / Displ.: 29.01
Disp: / Len: 200.26
Comfort Ratio: 25.36
Capsize Screening Formula: 1.94
S#: 2.76
Hull Speed: 7.52 kn
Pounds/Inch Immersion: 1,311.24 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 46.26 ft / 14.10 m
J: 13.78 ft / 4.20 m
P: 43.24 ft / 13.18 m
E: 14.60 ft / 4.45 m
S.A. Fore: 318.73 ft² / 29.61 m²
S.A. Main: 315.65 ft² / 29.32 m²
S.A. Total (100% Fore + Main Triangles): 634.38 ft² / 58.94 m²
S.A./Displ. (calc.): 17.52
Est. Forestay Length: 48.27 ft / 14.71 m
Mast Height from DWL: 53.75 ft / 16.38 m

Sailboat Links

Designers: Judel/Vrolijk & Co.
Builders: Hanse Yachts
Download Boat Record:

Notes

Shoal draft: 1.52m | 4.75'
