Sailboat Specifications

Definitions
Hull Type: Fin w/bulb & spade rudder
Rigging Type: Fractional Sloop
LOA: 44.36 ft / 13.52 m
LWL: 40.03 ft / 12.20 m
S.A. (reported): 1,021.00 ft² / 94.85 m²
Beam: 14.37 ft / 4.38 m
Displacement: 24,251.00 lb / 11,000 kg
Ballast: 7,716.00 lb / 3,500 kg
Max Draft: 7.38 ft / 2.25 m
Construction: FG
First Built: 2010
Builder: Hanse Yachts (GER)
Designer: Judel/Vrolijk

Auxiliary Power/Tanks (orig. equip.)

Type: Diesel
HP: 53
Fuel: 58 gals / 220 L

Accomodations

Water: 119 gals / 450 L

Sailboat Calculations

Definitions
S.A. / Displ.: 19.58
Bal. / Displ.: 31.82
Disp: / Len: 168.78
Comfort Ratio: 26.07
Capsize Screening Formula: 1.99
S#: 3.44
Hull Speed: 8.48 kn
Pounds/Inch Immersion: 2,055.36 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 57.48 ft / 17.52 m
J: 17.22 ft / 5.25 m
P: 54.30 ft / 16.55 m
E: 19.36 ft / 5.90 m
S.A. Fore: 494.90 ft² / 45.98 m²
S.A. Main: 525.62 ft² / 48.83 m²
S.A. Total (100% Fore + Main Triangles): 1,020.52 ft² / 94.81 m²
S.A./Displ. (calc.): 19.57
Est. Forestay Length: 60.00 ft / 18.29 m

Sailboat Links

Designers: Judel/Vrolijk & Co.
Builders: Hanse Yachts
Download Boat Record:

Notes

Shoal draft: 1.82 m/5.67´(option)
Re-design in 2013 (not shown).
