ISLAND PACKET ESTERO 36

ISLAND PACKET ESTERO 36

Beta Marine

Beta Marine

Sailboat Specifications

Definitions
Hull Type: Long Keel
Rigging Type: Masthead Sloop
LOA: 36.42 ft / 11.10 m
LWL: 31.43 ft / 9.58 m
S.A. (reported): 708.00 ft² / 65.78 m²
Beam: 12.34 ft / 3.76 m
Displacement: 19,299.00 lb / 8,754 kg
Ballast: 7,500.00 lb / 3,402 kg
Max Draft: 4.00 ft / 1.22 m
Construction: FG
First Built: 2009
Builder: Island Packet Yachts (USA)
Designer: Robert K. Johnson

Auxiliary Power/Tanks (orig. equip.)

Make: Yanmar
Type: Diesel
HP: 40
Fuel: 60 gals / 227 L

Accomodations

Water: 120 gals / 454 L

Sailboat Calculations

Definitions
S.A. / Displ.: 15.80
Bal. / Displ.: 38.86
Disp: / Len: 277.49
Comfort Ratio: 31.89
Capsize Screening Formula: 1.84
Hull Speed: 7.51 kn
Pounds/Inch Immersion: 1,385.82 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
Mast Height from DWL: 54.00 ft / 16.46 m
