Sailboat Specifications

Definitions
Hull Type: Fin w/bulb & spade rudder
Rigging Type: Fractional Sloop
LOA: 36.09 ft / 11.00 m
LWL: 31.76 ft / 9.68 m
S.A. (reported): 699.00 ft² / 64.94 m²
Beam: 11.75 ft / 3.58 m
Displacement: 11,453.00 lb / 5,195 kg
Ballast: 4,195.00 lb / 1,903 kg
Max Draft: 6.89 ft / 2.10 m
Construction: EGlass infusion. balsa & foam sandwich
Ballast Type: Lead + iron
First Built: 2015
Builder: J Composites (EU)
Designer: Johnstone

Auxiliary Power/Tanks (orig. equip.)

Make: Volvo
Model: D1-30
Type: Diesel
HP: 30
Fuel: 22 gals / 83 L

Accomodations

Water: 53 gals / 201 L

Sailboat Calculations

Definitions
S.A. / Displ.: 22.09
Bal. / Displ.: 36.63
Disp: / Len: 159.60
Comfort Ratio: 20.12
Capsize Screening Formula: 2.09
Hull Speed: 7.55 kn
Pounds/Inch Immersion: 1,333.41 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: Alan Johnstone
Builders: J Boats
Download Boat Record:

Notes

Shallow draft: 1.75m/5.75'
