Sailboat Specifications

Definitions
Hull Type: Fin w/spade rudder
Rigging Type: Masthead Sloop
LOA: 32.68 ft / 9.96 m
LWL: 27.00 ft / 8.23 m
S.A. (reported): 492.00 ft² / 45.71 m²
Beam: 10.93 ft / 3.33 m
Displacement: 10,670.00 lb / 4,840 kg
Ballast: 4,850.00 lb / 2,200 kg
Max Draft: 6.00 ft / 1.83 m
Construction: FG
Ballast Type: Iron
First Built: 1977
Builder: Lewin/FF Boats
Designer: Jac. de Ridder

Auxiliary Power/Tanks (orig. equip.)

Make: Yanmar
Model: 2QM20H
Type: Diesel
HP: 22
Fuel: 14 gals / 53 L

Accomodations

Water: 48 gals / 182 L

Sailboat Calculations

Definitions
S.A. / Displ.: 16.30
Bal. / Displ.: 45.45
Disp: / Len: 242.01
Comfort Ratio: 23.77
Capsize Screening Formula: 1.99
S#: 2.18
Hull Speed: 6.96 kn
Pounds/Inch Immersion: 1,054.46 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 42.80 ft / 13.05 m
J: 13.90 ft / 4.24 m
P: 38.20 ft / 11.64 m
E: 10.20 ft / 3.11 m
S.A. Fore: 297.46 ft² / 27.63 m²
S.A. Main: 194.82 ft² / 18.10 m²
S.A. Total (100% Fore + Main Triangles): 492.28 ft² / 45.73 m²
S.A./Displ. (calc.): 16.31
Est. Forestay Length: 45.00 ft / 13.72 m

Sailboat Links

Designers: Jacques De Ridder
Associations: IOR 3/4 ton
Download Boat Record:

Notes

Originally designed as IOR 3/4 ton.
Later called KALIK 103 and Q33.
Aft cabin version (KALIK 33 AC).
Some were sold to the charter trade as the OCEAN 33.
Thanks to Jan Derks for additional information.
