LION CLASS (ROBB)

LION CLASS (ROBB)
LION CLASS (ROBB)

Beta Marine

Beta Marine

Sailboat Specifications

Definitions
Hull Type: Fin Keel
Rigging Type: Masthead Sloop
LOA: 35.50 ft / 10.82 m
LWL: 25.00 ft / 7.62 m
S.A. (reported): 513.00 ft² / 47.66 m²
Beam: 8.75 ft / 2.67 m
Displacement: 14,200.00 lb / 6,441 kg
Ballast: 4,000.00 lb / 1,814 kg
Max Draft: 5.50 ft / 1.68 m
Construction: Teak/FG
First Built: 1951
Last Built: 1965
# Built: 150
Builder: Cheoy Lee Yachts (HK) Bickfords, Woodnutts (UK)
Designer: Arthur Robb

KLSC Leaderboard

KLSC Leaderboard

Sailboat Calculations

Definitions
S.A. / Displ.: 14.05
Bal. / Displ.: 28.17
Disp: / Len: 405.71
Comfort Ratio: 43.35
Capsize Screening Formula: 1.45
S#: 0.95
Hull Speed: 6.70 kn
Pounds/Inch Immersion: 781.62 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 38.30 ft / 11.67 m
J: 12.90 ft / 3.93 m
P: 34.80 ft / 10.61 m
E: 15.30 ft / 4.66 m
S.A. Fore: 247.04 ft² / 22.95 m²
S.A. Main: 266.22 ft² / 24.73 m²
S.A. Total (100% Fore + Main Triangles): 513.26 ft² / 47.68 m²
S.A./Displ. (calc.): 14.05
Est. Forestay Length: 40.41 ft / 12.32 m

Sailboat Links

Designers: Arthur Robb
Builders: Cheoy Lee Shipyard
Stebbings & Sons (UK)
Swanson Brothers (AUS)
Download Boat Record:

Notes

One of Arthur Robb's most popular designs and a very successful racer. (A sister ship was winner of the Sidney-Hobart Race in 1959 & 1960).
Cheoy Lee shipyard built at least 20 boats of teak, many which went to the US. By the mid 1960's the same yard had developed a fiberglass version also for export to the US and elsewhere. Rig type and dimensions vary widely. The original drawings show a fractional rig.
