Sailboat Specifications

Definitions
Hull Type: Keel/Cbrd.
Rigging Type: Masthead Sloop
LOA: 19.03 ft / 5.80 m
LWL: 16.73 ft / 5.10 m
Beam: 7.55 ft / 2.30 m
Displacement: 1,953.00 lb / 886 kg
Max Draft: 3.61 ft / 1.10 m
Min Draft: 1.97 ft / 0.60 m
Construction: FG
Ballast Type: Iron
First Built: 1977
Builder: Newbridge Boats Ltd.
Designer: Robert Tucker

Sailboat Calculations

Definitions
Disp: / Len: 186.19
Comfort Ratio: 11.72
Capsize Screening Formula: 2.42
Hull Speed: 5.48 kn
Pounds/Inch Immersion: 451.32 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: Robert Tucker
Builders: Newbridge Boats Ltd. (UK)
Download Boat Record:

Notes

Fin and bilge keel versions.
