Sailboat Specifications

Definitions
Hull Type: Fin with rudder on skeg
Rigging Type: Masthead Sloop
LOA: 36.17 ft / 11.02 m
LWL: 29.50 ft / 8.99 m
S.A. (reported): 683.00 ft² / 63.45 m²
Beam: 12.00 ft / 3.66 m
Displacement: 16,940.00 lb / 7,684 kg
Ballast: 8,140.00 lb / 3,692 kg
Max Draft: 6.42 ft / 1.96 m
Construction: FG
First Built: 1972
Builder: Solna Marine (SWE)
Designer: Peter Norlin

Sailboat Calculations

Definitions
S.A. / Displ.: 16.63
Bal. / Displ.: 48.05
Disp: / Len: 294.58
Comfort Ratio: 30.36
Capsize Screening Formula: 1.87
S#: 1.76
Hull Speed: 7.28 kn
Pounds/Inch Immersion: 1,264.88 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 50.60 ft / 15.42 m
J: 16.00 ft / 4.88 m
P: 44.90 ft / 13.69 m
E: 12.40 ft / 3.78 m
S.A. Fore: 404.80 ft² / 37.61 m²
S.A. Main: 278.38 ft² / 25.86 m²
S.A. Total (100% Fore + Main Triangles): 683.18 ft² / 63.47 m²
S.A./Displ. (calc.): 16.63
Est. Forestay Length: 53.07 ft / 16.18 m

Sailboat Links

Designers: Peter Norlin
