PEARSON 530

Sailboat Specifications

both US imperial metric

Hull Type:

Fin with rudder on skeg

Rigging Type:

Staysail Ketch

LOA:

53.00 ft / 16.15 m

LWL:

45.00 ft / 13.72 m

Beam:

15.00 ft / 4.57 m

S.A. (reported):

1,232.00 ft² / 114.46 m²

Draft (max):

6.83 ft / 2.08 m

Displacement:

43,000 lb / 19,504 kg

Ballast:

16,000 lb / 7,257 kg

S.A./Disp.:

16.13

Bal./Disp.:

37.21

Disp./Len.:

210.66

Construction:

FG

Ballast Type:

Lead

First Built:

1981

Last Built:

1985

Builder:

Pearson Yachts (USA)

Designer:

William Shaw

Auxiliary Power/Tanks (orig. equip.)

Make:

Perkins

Model:

4.236

Type:

Diesel

HP:

85

Fuel:

170 gals / 644 L

Sailboat Calculations

Definitions

S.A./Disp.:

16.13

Bal./Disp.:

37.21

Disp./Len.:

210.66

Comfort Ratio:

38.07

Capsize Screening Formula:

1.72

S#:

2.16

Rig and Sail Particulars

help

I:

58.00 ft / 17.68 m

J:

19.00 ft / 5.79 m

P:

51.50 ft / 15.70 m

E:

18.75 ft / 5.72 m

PY:

32.95 ft / 10.04 m

EY:

12.00 ft / 3.66 m

S.A. Fore:

551.00 ft² / 51.19 m²

S.A. Main:

482.81 ft² / 44.85 m²

S.A. Total (100% Fore + Main Triangles)

1,033.81 ft² / 96.04 m²

S.A./Disp. (calc.):

13.54

Est. Forestay Len.:

61.03 ft / 18.60 m

Mast Height from DWL:

64.00 ft / 19.51 m

Accommodations

Water:

280 gals / 1,060 L

Sailboat Links

Designers:

William Shaw

Builders:

Pearson Yachts

Download Boat Record:

PDF

Notes

The largest boat built under the Pearson brand.
Keel/CB version also available.
Draft (max.) 10.17'/3.10m; Draft (min.) 5.75'/1.75m
Disp. 43000 lbs./19505 kgs.;Ballast: 15000 lbs./6804 kgs.
From builders brochure.
