Sailboat Specifications

Definitions
Hull Type: Long Keel
Rigging Type: Masthead Ketch
LOA: 28.00 ft / 8.53 m
LWL: 24.00 ft / 7.32 m
S.A. (reported): 348.00 ft² / 32.33 m²
Beam: 6.33 ft / 1.93 m
Displacement: 6,611.00 lb / 2,999 kg
Ballast: 3,360.00 lb / 1,524 kg
Max Draft: 3.75 ft / 1.14 m
Construction: Wood or FG
First Built: 1952
Designer: L. Francis Herreshoff

Sailboat Calculations

Definitions
S.A. / Displ.: 15.86
Bal. / Displ.: 50.82
Disp: / Len: 213.49
Comfort Ratio: 34.68
Capsize Screening Formula: 1.35
S#: 1.97
Hull Speed: 6.56 kn
Pounds/Inch Immersion: 542.83 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 24.00 ft / 7.32 m
J: 8.00 ft / 2.44 m
P: 27.80 ft / 8.47 m
E: 12.50 ft / 3.81 m
S.A. Fore: 96.00 ft² / 8.92 m²
S.A. Main: 173.75 ft² / 16.14 m²
S.A. Total (100% Fore + Main Triangles): 269.75 ft² / 25.06 m²
S.A./Displ. (calc.): 12.29
Est. Forestay Length: 25.30 ft / 7.71 m

Sailboat Links

Designers: L. Francis Herreshoff
Builders: Kenner Boat Company
South Coast Seacraft Co.
Download Boat Record:

Notes

The plans for the ROZINANTE first appeared as part of an article authored by the designer for 'The Rudder' Magazine.

Reported sail area:
- Main: 180 ft²
- Jib: 98 ft²
- Mizzen 70 ft²

Specs from "Sensible Cruising Designs" by L. Francis Herreshoff © 1973 by International Marine®, a division of McGraw-Hill
