Sailboat Specifications

Definitions
Hull Type: Centerboard (Trunk)
Rigging Type: Fractional Sloop
LOA: 16.83 ft / 5.13 m
LWL: 15.58 ft / 4.75 m
S.A. (reported): 152.00 ft² / 14.12 m²
Beam: 6.75 ft / 2.06 m
Displacement: 1,300.00 lb / 590 kg
Ballast: 120.00 lb / 54 kg
Max Draft: 3.50 ft / 1.07 m
Min Draft: 1.75 ft / 0.53 m
Construction: FG
First Built: 2011
Builder: Sage Marine (USA)
Designer: Jerry Montgomery

Sailboat Calculations

Definitions
S.A. / Displ.: 20.46
Bal. / Displ.: 9.23
Disp: / Len: 153.46
Comfort Ratio: 9.89
Capsize Screening Formula: 2.48
Hull Speed: 5.29 kn
Pounds/Inch Immersion: 375.77 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
Mast Height from DWL: 25.00 ft / 7.62 m

Sailboat Links

Builders: Sage Marine (USA)
Download Boat Record:

Notes

Fixed keel version also available.
